BLAST 60/45
60 gallons to −40 °C in 45 minutes
BLAST Ethanol Chiller Comparison
Compare BLAST™ 60/45, 150/45, 150/30, and 240/45 ethanol chillers.
Pick the production class that matches your ethanol volume, centrifuge workflow, facility utilities, and throughput target.
BLAST 150/45
150 gallons to −40 °C in 45 minutes
BLAST 150/30
150 gallons to −40 °C in 30 minutes
BLAST 240/45
240 gallons to −40 °C in 45 minutes
Comparison Chart
Four ethanol chillers, one production-class decision.
| Spec / Fit | BLAST 60/45 | BLAST 150/45 | BLAST 150/30 | BLAST 240/45 |
|---|---|---|---|---|
| Ethanol capacity | 60 gallons | 150 gallons | 150 gallons | 240 gallons |
| Pull-down target | Room temperature to −40 °C | Room temperature to −40 °C | Room temperature to −40 °C | Room temperature to −40 °C |
| Target timing | 45 minutes | 45 minutes | 30 minutes | 45 minutes |
| Flash-chilling rate | 1.33 GPM | 3.33 GPM | 5 GPM | 6.0 GPM |
| Best production fit | Compact production | Mid-scale production | High-speed mid-scale production | Large process class |
| Workflow match | 30-gallon centrifuge or 2x 15-gallon workflow | Growing commercial extraction schedules | Faster 150-gallon repeat cycles | Higher-volume extraction schedules |
| System architecture | Dual-stage cascade design | Direct refrigerant chilling | 22 HP + 6 HP cascade with regeneration | Direct refrigerant chilling |
| Controls | PLC/HMI visibility | PLC/HMI visibility | Mirage 1.0 PLC/HMI | PLC/HMI visibility |
| Facility integration | Outdoor condenser units | HVAC condenser integration | Three-zone coordinated installation | HVAC condenser integration |
Quick Recommendation
Use the chiller size that matches the bottleneck you are solving.
Choose 60/45 for compact speed
Best when the workflow centers on a 30-gallon centrifuge class and the facility wants a serviceable, lower-temperature cascade design.
Choose 150/45 for the middle lane
Best when production has moved past pilot scale and needs more chilling capacity without stepping into the largest process class.
Choose 150/30 for faster 150-gallon cycles
Best when the operation needs 150-gallon capacity with five-gallon-per-minute chilling, cascade subcooling, and regenerative heat transfer.
Choose 240/45 for volume
Best when the operation needs the largest BLAST ethanol capacity, faster schedule support, and room for higher production volume.
Model Details
Compare each BLAST chiller in context.
BLAST 60/45
- 60 gallons capacity
- 1.33 GPM
- PLC/HMI visibility
- Two outdoor condenser units
Labs that want a compact, serviceable ethanol chiller with strong low-temperature performance and a clean path away from LN2 or dry ice.
View BLAST 60/45BLAST 150/45
- 150 gallons capacity
- 3.33 GPM
- PLC/HMI visibility
- HVAC condenser integration
Teams that have outgrown compact chilling capacity and need a stronger production-class target without jumping to the largest unit.
View BLAST 150/45BLAST 150/30
- 150 gallons capacity
- 5 GPM
- Mirage 1.0 PLC/HMI visibility
- Two aligned outdoor condenser units
Teams that need 150-gallon capacity with faster pull-down, cascade subcooling, regenerative chilling, and coordinated control across all three equipment zones.
View BLAST 150/30BLAST 240/45
- 240 gallons capacity
- 6.0 GPM
- PLC/HMI visibility
- HVAC condenser integration
Facilities planning around higher ethanol volume, larger production schedules, and a stronger path away from consumable-heavy cooling.
